Kito Pwb Girder Clamp
Features
- Featuring a single-threaded adjustment pin for simple and easy installation, Girder Clamps are supplied in a durable electrostatic enamel finish.
- Note: Maximum headroom for narrowest beam width.
- Headroom decreases as beam width is increased.
Specifications
| Capacity | Part No. | Beam Range (mm) |
Headroom (min/mm) |
Headroom (max/mm) |
Suspension pin dia. (mm) |
Weight* (kg) |
| 1 tonne | 48246 | 65-230 | 78 | 135 | 20.3 | 4.8 |
| 2 tonne | 48247 | 65-230 | 78 | 135 | 20.3 | 5.5 |
| 3 tonne | 48248 | 100-250 | 100 | 160 | 22.1 | 11.8 |
| 5 tonne | 48249 | 100-320 | 119 | 159 | 40.0 | 16.0 |
| 10 tonne | 48476 | 130-320 | 150 | 205 | 53.0 | 31.0 |
Applications
- Construction
- Manufacturing
- Entertainment
- Mining
- General engineering
