Manual Chain Blocks

Features

Full Body Steel cast construction, gear case and reinforced side covers are impact resistant
Unique design on top and bottom hooks with ball bearings and safety catches
Beaver ‘ID’ plates and rivets are supplied in stainless steel (a non-conductive material) in order to avoid dangerous sparking,
Comprehensive range of spare parts are available
Colour coded to match international Lifting standards
Every 3S Chain Block is identified with its own serial number that relates directly to a test certificate
Complies to AS/NZS 1418.2
Grade 80 Calibrated Chain and marked according to ISO 3077

Get A quote

Call Us: 07 3205 7000

Description
Additional information
Specifications

Beaver 3S industrial chain blocks are designed for use on monorails, jibs fixed installations and for maintenance use. These chain blocks or hoists are to be used for vertical lifts only. If they are side loaded or used horizontally, jamming of the loader chain and damage to the blocks may occur. The Beaver 3S industrial chain blocks features a double pawl and double roller guide for enhanced performance and reliability, as well as a unique curling design which enables the hand chain to successfully feed directly into the wheel sprocket. Individual test certificate and Operational Manual included in the packaging.

Additional information

Lift Length	3m, 6m
Rated Capacity	500g, 1t, 2t, 3t, 5t, 10t, 20t

Specifications

Product Code	Rated Capacity	Colour Code	Standard Lift	Effort on Lever to Lift Full Load	No. Load Chain Falls	Load Chain Diameter
CB0.5X3-BEAVER	0.5t	White	3m	240kg	1	5mm x 15mm
CB1X3-BEAVER	1t	Violet	3m	250kg	1	6mm x 18mm
CB2X3-BEAVER	2t	Green	3m	335kg	1	8mm x 24mm
CB3X3_BEAVER	3t	Yellow	3m	265kg	2	8mm x 24mm
503503	5t	Red	3m	360kg	2	9mm x 30mm
503603	10t	Orange	3m	380kg	4	9mm x 30mm
CB0.5X6-BEAVER	0.5t	White	6m	240kg	1	5mm x 15mm
CB1X6-BEAVER	1t	Violet	6m	250kg	1	6mm x 18mm
CB2X6-BEAVER	2t	Green	6m	335kg	1	8mm x 24mm
CB3X6-BEAVER	3t	Yellow	6m	335kg	2	8mm x 24mm
CB5X6-BEAVER	5t	Red	6m	363kg	2	9mm x 30mm
503606	10t	Orange	6m	380kg	4	9mm x 30mm
