Round Slings up to 8,000kg

Features

  • Variable load bearing point for more even wear
  • Ideal for choke lifting cylindrical objects
  • Lifts smooth objects without damage
  • Lightweight and soft
  • Reduced manual handling injuries
  • High strength to weight ratio
  • Load bearing fibres protected by the outer sleeve
  • Wide choice of lifting modes
  • Tuff Tag, webbing reinforced encapsulated compliance labels
  • Certified to AS.4497
Product Enquiry

Additional information

Length

1m, 2m, 3m, 4m, 5m, 6m, 8m

WLL

1000, 2000, 3000, 4000, 5000, 6000, 8000, 10000, 15000, 20000, 30000, 40000, 50000

Specifications

Colour/
Code
Rated WLL(kg) Thickness Under Load(mm approx.) Width Under Load (mm approx.) Minimum Load Edge Radius (mm) Minimum Load Edge Diametre with Secutex Sleeve Maximum Length (metres) Minimum Length (metres) Weight per Metre (kg)
Purple E1000 1000 6 45 18 N/A 60 0.5 0.3
Teal E2000 2000 7 48 21 N/A 60 0.5 0.5
Yellow E3000 3000 8 60 24 N/A 60 0.5 0.80
Grey E4000 4000 10 65 30 N/A 60 1.0 1.00
Red E5000 5000 10 75 30 N/A 60 1.0 1.20
Brown E6000 6000 13 80 39 N/A 60 1.0 1.40
Blue E8000 8000 15 80 45 N/A 60 1.0 1.80



Colour/Code Rated WLL(kg) 1 Metre 2 Metre 3 Metre 4 Metre 5 Metre 6 Metre 8 Metre
Purple E1000 1000 E1000-0x1.0 E1000-0x2.0 E1000-0x3.0 E1000-0x4.0 E1000-0x5.0 E1000-0x6.0 E1000-0x8.0
Teal E2000 2000 E2000-0x1.0 E2000-0x2.0 E2000-0x3.0 E2000-0x4.0 E2000-0x5.0 E2000-0x6.0 E2000-0x8.0
Yellow E3000 3000 E3000-0x1.0 E3000-0x2.0 E3000-0x3.0 E3000-0x4.0 E3000-0x5.0 E3000-0x6.0 E3000-0x8.0
Grey E4000 4000 E4000-0x1.0 E4000-0x2.0 E4000-0x3.0 E4000-0x4.0 E4000-0x5.0 E4000-0x6.0 E4000-0x8.0
Red E5000 5000 E5000-0x1.0 E5000-0x2.0 E5000-0x3.0 E5000-0x4.0 E5000-0x5.0 E5000-0x6.0 E5000-0x8.0
Brown E6000 6000 E6000-0x1.0 E6000-0x2.0 E6000-0x3.0 E6000-0x4.0 E6000-0x5.0 E6000-0x6.0 E6000-0x8.0
Blue E8000 8000 E8000-0x1.0 E8000-0x2.0 E8000-0x3.0 E8000-0x4.0 E8000-0x5.0 E8000-0x6.0 E8000-0x8.0
Orange E10000 10000 E10000-0x1.0 E10000-0x2.0 E10000-0x3.0 E10000-0x4.0 E10000-0x5.0 E10000-0x6.0 E10000-0x8.0
Orange E15000 15000 E15000-0x1.0 E15000-0x2.0 E15000-0x3.0 E15000-0x4.0 E15000-0x5.0 E15000-0x6.0 E15000-0x8.0
Orange E20000 20000 E20000-0x1.0 E20000-0x2.0 E20000-0x3.0 E20000-0x4.0 E20000-0x5.0 E20000-0x6.0 E20000-0x8.0
Orange E30000 30000 E30000-0x1.0 E30000-0x2.0 E30000-0x3.0 E30000-0x4.0 E30000-0x5.0 E30000-0x6.0 E30000-0x8.0
Orange E40000 40000 E40000-0x1.0 E40000-0x2.0 E40000-0x3.0 E40000-0x4.0 E40000-0x5.0 E40000-0x6.0 E40000-0x8.0
Orange E50000 50000 E50000-0x1.0 E50000-0x2.0 E50000-0x3.0 E50000-0x4.0 E50000-0x5.0 E50000-0x6.0 E50000-0x8.0



Colour/ Code secutex Code Single Sided Interior Width Exterior Width Exterior Height Weight Per Run Metre
Purple E1000 SFI-50 50 70 22 0.9
Teal E2000 SFI-75 75 95 22 1.3
Yellow E3000 SFI-100 100 120 22 1.5
Grey E4000 SFI-140 140 160 22 2.1
Red E5000 SFI-150 150 170 22 2.1
Brown E6000 SFI-180 180 200 35 2.7
Blue E8000 SFI-240 240 260 35 3.2



Colour/ Code secutex Code Single Sided Interior Width Exterior Width Exterior Height Weight Per Run Metre
Purple E1000 SF2-50 50 70 70 1.2
Teal E2000 SF2-75 75 95 95 1.8
Yellow E3000 SF2-100 100 120 120 2.1
Grey E4000 SF2-140 140 160 160 3.0
Red E5000 SF2-150 150 170 170 3.0
Brown E6000 SF2-180 180 200 35 3.3
Blue E8000 SF2-240 240 260 35 4.2



Colour/ Code secutex Code Single Sided Interior Width Exterior Width Exterior Height Weight Per Run Metre
Purple E1000 SC-50 50 70 70 1.1
Teal E2000 SC-75 75 95 95 1.6
Yellow E3000 SC-100 100 120 120 1.8
Grey E4000 SC-140 140 160 160 2.6
Red E5000  SC-150 150 170 170 2.6
Brown E6000 SC-180 180 200 35 3.3
Blue E8000 SC-240 240 260 35 4.2
