High Performance Low Mass Round Slings
Features
- Up to 250,000kg
- Up to 50% lighter than conventional round slings for even better manual handling
- Internal fibres and external tube are the same material and comply to AS4497.1
- Up to 50% slimmer than conventional round slings
- Can be laid against tighter edge radii than conventional PES slings
- Shackle and hardware interface is therefore less crowded
- Reinforced high performance woven cover
- Variable load bearing point for more even wear
- Ideal for choke lifting cylindrical objects without creasing
- Less creasing means less wear
- WLL data woven into sleeve for unmistakable capacity identification
- Lifts smooth objects without damage
- High strength to weight ratio
- Load bearing fibres protected by the outer sleeve
- Wide choice of lifting modes
Additional information
| Dimensions | N/A |
|---|---|
| WLL | 10000, 20000, 25000, 30000, 40000, 50000, 60000, 80000, 100000, 125000, 150000 |
| Length | 2.5m, 3m, 4m, 5m, 6m, 8m |
Specifications
| Colour/ Code | Rated WLL (kg) | Thickness Under Load (mm approx.) | Width Under Load (mm approx.) | Minimum Load Edge Radius (mm) | Minimum Load Edge Diametre with secutex Sleeve | Maximum Length (metres) | Minimum Length (metres) | Weight Per Metre (kg) | |
|
10,000 | 12 | 55 | 36 | N/A | 60 | 1.8 | 1 | |
|
20,000 | 15 | 80 | 45 | N/A | 60 | 1.8 | 2.3 | |
|
25,000 | 18 | 85 | 54 | N/A | 60 | 1.8 | 2.9 | |
|
30,000 | 20 | 90 | 60 | N/A | 60 | 1.8 | 3.5 | |
|
40,000 | 24 | 110 | 72 | N/A | 60 | 1.8 | 5.1 | |
|
50,000 | 26 | 120 | 28 | N/A | 60 | 1.8 | 5.5 | |
|
60,000 | 36 | 153 | 138 | N/A | 60 | 2 | 7.9 | |
|
80,000 | 48 | 204 | 154 | N/A | 60 | 2 | 10.9 | |
|
100,000 | 56 | 238 | 168 | N/A | 60 | 2 | 16.8 | |
|
125,000 | 70 | 272 | 210 | N/A | 60 | 4 | 20.4 | |
|
150,000 | 80 | 315 | 240 | N/A | 60 | 4 | 25.4 |
| Colour/ Code | Rated WLL (kg) | 2.5 metre | 3 metre | 4 metre | 5 metre | 6 metre | 8 metre | |
|
10,000 | MF10000 – 0x2.5 | MF10000 – 0x3.0 | MF10000 – 0x4.0 | MF10000 – 0x5.0 | MF10000 – 0x6.0 | MF10000 -0x8.0 | |
|
20,000 | MF20000 – 0x2.5 | MF20000 – 0x3.0 | MF20000 – 0x4.0 | MF20000 – 0x5.0 | MF20000 – 0x6.0 | MF20000 -0x8.0 | |
|
25,000 | MF25000 – 0x2.5 | MF25000 – 0x3.0 | MF25000 – 0x4.0 | MF25000 – 0x5.0 | MF25000 – 0x6.0 | MF25000 -0x8.0 | |
|
30,000 | MF30000 – 0x2.5 | MF30000 – 0x3.0 | MF30000 – 0x4.0 | MF30000 – 0x5.0 | MF30000 – 0x6.0 | MF30000 -0x8.0 | |
|
40,000 | MF40000 – 0x2.5 | MF40000 – 0x3.0 | MF40000 – 0x4.0 | MF40000 – 0x5.0 | MF40000 – 0x6.0 | MF40000 -0x8.0 | |
|
50,000 | MF50000 – 0x2.5 | MF50000 – 0x3.0 | MF50000 – 0x4.0 | MF50000 – 0x5.0 | MF50000 – 0x6.0 | MF50000 -0x8.0 | |
|
60,000 | MF60000 – 0x2.5 | MF60000 – 0x3.0 | MF60000 – 0x4.0 | MF60000 – 0x5.0 | MF60000 – 0x6.0 | MF60000 -0x8.0 | |
|
80,000 | MF80000 – 0x2.5 | MF80000 – 0x3.0 | MF80000 – 0x4.0 | MF80000 – 0x5.0 | MF80000 – 0x6.0 | MF80000 – 0x8.0 | |
|
100,000 | MF100000 – 0x2.5 | MF100000 – 0x3.0 | MF100000 – 0x4.0 | MF100000 – 0x5.0 | MF100000 – 0x6.0 | MF100000 – 0x8.0 | |
|
125,000 | MF125000 – 0x2.5 | MF125000 – 0x3.0 | MF125000 – 0x4.0 | MF125000 – 0x5.0 | MF125000 – 0x6.0 | MF125000 – 0x8.0 | |
|
150,000 | MF150000 – 0x2.5 | MF150000 – 0x3.0 | MF150000 – 0x4.0 | MF150000 – 0x5.0 | MF150000 – 0x6.0 | MF150000 – 0x8.0 |
| Colour/ Code | secutex Code Single Sided | Interior Width (mm) | Exterior Width (mm) | Exterior Height | Weight Per Run | |
|
SFI-CS-120 | 120 | 145 | 45 | 1.7 | |
|
SFI-CS-180 | 180 | 230 | 35 | 3 | |
|
SFI-CS-240 | 240 | 265 | 35 | 3.1 | |
|
SFI-CS-300 | 300 | 330 | 33 | 3.8 |
| Colour/ Code | secutex Code Single Sided | Interior Width (mm) | Exterior Width (mm) | Exterior Height | Weight Per Run | |
|
SF2-CS-180 | 180 | 230 | 37 | 3.4 | |
|
SF2-CS-300 | 300 | 330 | 35 | 4.2 | |
|
SF2-CS-300 | 300 | 330 | 35 | 5.6 | |
|
SF2-CS-300 | 300 | 330 | 33 | 6.6 |
| Colour/ Code | secutex Code Single Sided | Interior Width (mm) | Exterior Width (mm) | Exterior Height | Weight Per Run | |
|
SC-CS-180 | 180 | 230 | 37 | 3.3 | |
|
SC-CS-300 | 300 | 330 | 35 | 4.1 | |
|
SC-CS-300 | 300 | 330 | 35 | 5 | |
|
SC-CS-300 | 300 | 330 | 33 | 6.4 |
